XGN15-12 Inflatable Ring Network Switchgear
Scope of application:
XGN15-12 Fixed type metal ring main switchgear is a new generation of metal enclosed switchgear that uses SF6 load switches as switches and uses air insulation throughout the cabinet.It is suitable for distribution automation and is compact and expandable.It has the characteristics of high-end,miniaturization,full parameters,low price,and less maintenance. This product has a"closing-opening-grounding"three position arc extinguishing chamber, equipped witha"five prevention"function(to prevent loaded opening and closing of the main switch;to prevent accidental entry into the live space;to prevent accidental opening and closing of the main switch;to prevent live hanging of the grounding wire;to prevent the grounding switch from transmitting power in the grounding position),reliable interlocking, high insulation strength of the fracture,large creepage distance design,and the outlet end is protected by a pressure equalizing cover,with a special dynamic sealing and fixed sealing design,Combined with advanced technical performance and lightweight and flexible assembly solutions,it can fully meet the constantly changing requirements of the market and is a new generation of high-voltage switchgear equipped in urban power grids.ABB's original SFG Sf6 load switch or Schneider's original SM6 load switch can also be installed according to user needs.Or install an imported vacuum circuit breaker VD4 switch.
This product is suitable for three-phase AC 10kV,50Hz power systems,and is used in industrial and mining enterprises,high-rise buildings,residential communities,prefabricated substations, and other places to disconnect and close load currents,fault curents,control and protect lines and distribution transformers.
